Computed tomography (CT)

Computed tomography is an imaging technique that is an important diagnostic tool in many modern veterinary practices due to its speed and simplicity, as well as the high diagnostic value of the images it produces.

INHALT
How it works Implementation Areas of application
How it works

Computed tomography is an X-ray technique in which the X-ray tube and detector rotate around the object being examined, producing several hundred cross-sectional images. The final CT image is created by a computer, which compiles the measured data into an image. This allows for a clear representation of bones and different soft tissues without any overlap.

The CT scanner consists of a short tunnel, also called a gantry, and a mobile examination table on which the patient moves through the gantry. The X-ray tube located in the gantry rotates around the patient's body and regularly emits fan-shaped X-rays that pass through the body and are measured by detectors on the opposite side

Implementation

The CT scan usually takes only a few minutes. Nevertheless, correct positioning without movement is essential for obtaining clear images. Animals must therefore be placed under superficial anesthesia for the examination. Depending on the area of the body to be examined, animals are placed on the examination table in a supine, lateral, or prone position.

Areas of application

In small animals, computed tomography can be used to examine all regions of the body. Computed tomography is particularly suitable for the diagnosis of fissures (hairline cracks in the bone) and complicated fractures, but also for inflammation, tumors, malpositions, and anomalies due to its interference-free imaging.

Due to the size of horses, CT scans are limited to the head and limbs. Devices with a particularly large gantry opening also allow the cervical spine to be examined. CT scans are used in horses for further lameness diagnostics, among other things. Even on the head, an accurate diagnosis is often only possible through the superimposition-free representation of anatomical structures using computed tomography.

In rabbits and guinea pigs, computed tomography is ideal for diagnosing dental and ear diseases, but also for imaging the skull, all organs, the large blood vessels, and the entire body. To avoid the risk of anesthesia, a awake CT scan can also be performed on small pets.
